110cc ATV Engines Auto Clutch With Reverse Gear 3+1 And 1+1

Our 110 series air-cooled, four-stroke engines are designed for all-terrain vehicles, multi-purpose tricycles, and compact vehicles.It comes in both reverse and multi-gear versions, offering a balanced advantage in reliability and cost control. Every product is guaranteed to be brand new and undergoes 100% performance testing before leaving the factory. The average daily production capacity is a stable 800 units.





Main Technical Specifications
Model:	152FMH
Type:	Single cylinder,four-stroke,air-cooled
Displacement:	107 ml
Bore x Stroke:	52.4 mm x 49.5 mm
Rated Power & Rotating Speed:	4.7/8000 KW/(r/min)
Max.Torque & Rotating Speed:	6.9/5500 N.m/(r/min)
ldling Speed:	1500±150 r/min
Min.Fuel Consumption:	≤ 367 g/KW.h
lgnition:	CDI
Starter:	Electric/Kick
Lubrication:	Pressure/Splash
Transmission:	4speed ,Rotary





① 110cc ATV Engine with Reverse:
Features a 1+1 gearbox (1 forward gear + 1 reverse gear). Includes a direct installation kit for Coolster 110 ATVs, allowing for easy compatibility and installation. Ideal for maneuvering in confined spaces such as orchards and warehouses.



② 110cc Automatic Transmission Engine (with Reverse):
Equipped with an automatic clutch system to reduce operating steps. Features a 3+1 transmission (3 forward gears + 1 reverse gear). Suitable for all-terrain vehicles.



③ Standard 110cc All-Terrain Vehicle Engine:
Designed for ATVs used by users aged 8–15.

Preset mounting brackets are available for Coolster, Hisun, and Loncin brand vehicles, allowing installation without additional modification.



Central Asian Market: Equipped with a cyclone air filter that filters over 95% of sand and dust particles ≥0.3μm in diameter, making it suitable for desert environments.
West African Market: The carburetor uses zinc-nickel alloy plating and passes the ISO 9227 salt spray test. Rust resistance is improved by 40% in humid coastal conditions.
European Market: Comes with a pre-installed speed limiter (maximum speed ≤45 km/h), compliant with L1e and Euro III emission standards.





Logo Customization: Minimum order quantity: 50 units. Vector graphic files required.
Graphic Customization: Minimum order quantity: 50 units. Supports body appearance printing.
Color Options: Silver (anodized), black (high-temperature paint), gold (electroplated).
Gearbox Upgrade: The 1+1 gearbox can be upgraded to a 3+1 configuration. Vehicle model and usage scenario must be provided.
Performance Kit Upgrade: High-torque camshaft for a 20% power increase.
Anti-Skid Plate Upgrade: Made of 3mm thick cold-rolled steel, with impact resistance meeting ISO 13232 standards.

For other custom requests (such as special paint finishes), please contact us for details.
